Frame
High-performance hydroformed alloy, removable integrated battery, internal cable routing, motor armour, post-mount disc.
Fork
SR Suntour NVX30, coil spring, preload adjuster, 100 mm QR, 60 mm travel.
Hub Front
Alloy, CenterLock disc, 100 mm thru axle.
Hub Rear
Shimano Nexus 5-speed internal with CentreLock disc and coaster brake, 32h.
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve.
Spokes
14 g stainless steel, black.
Tyre
Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40".
Charger
Bosch standard 4A, 230V, smart system.
Controller
Bosch Intuvia 100, smart system.
Computer
Bosch LED remote, smart system.
Motor
Bosch Performance Line, 250 W, 75 Nm, 20 mph (25 km/h in Europe).
Shifter
Shimano Nexus C7000, 5-speed.
Crank
Size: XS, S, M - ProWheel alloy, 170 mm length. Size: L, XL - ProWheel alloy, 175 mm length.
Chainring
ProWheel 38T narrow/wide steel, with alloy guard.
Cassette
Shimano C7000 sprocket for Nexus, 27T.
Chain
Shimano HG40, 6/7/8-speed.
Pedal
Bontrager City pedals.
Saddle
Bontrager Boulevard.
Seatpost
Alloy, suspension, 31.6 mm, 300 mm length.
Handlebar
Alloy, 31.8 mm clamp, 25 mm rise, 630 mm width.
Grips
Bontrager Satellite Elite, alloy lock-on.
Stem
Size: XS, S, M - Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length. Size: L, XL - Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length.
Brake
Shimano MT200 hydraulic disc.
Brake Rotor
Size: XS, S, M, L, XL - Shimano RT10, CenterLock, 160 mm. Size: XS, S, M, L, XL - Shimano RTC60, 6-bolt, 160 mm.
Light
Size: XS, S, M, L, XL - Spanninga SOLO for e-bike. Size: XS, S, M, L, XL - Herrmans H-Black MR5-E.
Kickstand
Pletscher Comp Flex 18.
Cargo Rack
Alloy rear rack, 25 kg max weight.
Mudguard
Size: XS, S, M, L, XL - SKS plastic, front. Size: XS, S, M, L, XL - SKS plastic, rear.
Weight
M - 26.00 kg / 57.33 lbs (excluding battery).
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
