Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork (Size: S)
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
Fork (Size: M, L, XL)
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
Max Compatible Fork Travel
See service manual
Hub Front
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Hub Rear
Shimano TC500 alloy, CentreLock, 148x12 mm thru axle
Rim (Size: S, M, L, XL)
Bontrager Line TLR 30, Tubeless-Ready, 28-hole, Presta valve
Rim (Size: S, M, L, XL)
Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve
Spokes
14 g stainless steel, black
Max Tyre Size
See service manual
Battery
Bosch PowerTube 800 Wh, smart system
Charger
Bosch standard 4A, 230V, smart system
Computer
Bosch Purion 200
Motor
Bosch Performance Line CX, 20 mph (25 km/h in Europe)
Shifter
Shimano Deore M6100, 12-speed
Rear Derailleur
Shimano XT M8100, long cage
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Pedal
VP-536 nylon platform
Max. Chainring Size
1x: 42T
Saddle
Bontrager Commuter Comp
Seatpost (Size: S)
Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
Seatpost (Size: M, L, XL)
Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Handlebar
Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips
Bontrager XR Endurance Comp, lock-on
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Head Set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake
Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliper
Brake Rotor
Shimano RT64, CentreLock, 203 mm
Rotor Size
Max brake rotor sizes – Frame: 203mm, min 180 mm, fork: see fork manufacturer
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
