Frame
SL OCLV Mountain Carbon, IsoStrut, UDH, 80 mm travel
Fork
RockShox SID, DebonAir spring, Rush RL damper, remote lockout, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 110 mm travel
Shock
Trek IsoStrut, RockShox SIDLuxe, 2-position remote damper
Max Compatible Fork Travel
120mm, min 100mm
Wheel Front
Bontrager Kovee Comp 25, Tubeless-Ready, 6-bolt, Boost110, 15 mm thru-axle, 29"
Wheel Rear
Bontrager Kovee Comp 25, Tubeless-Ready, Rapid Drive 108, Boost148, 12 mm thru axle, 29"
Tyre
Bontrager Sainte-Anne RSL XR, Tubeless Ready, dual compound, aramid bead, 220 tpi, 29x2.40"
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Max Tyre Size
Frame: 29x2.40", Fork: See manufacturer
Battery
SRAM eTap battery pack (with charger)
Shifter
SRAM AXS POD
Rear Derailleur
SRAM GX Eagle AXS, T-Type
Crank (Size: S, M, ML)
SRAM GX Eagle, DUB, T-Type, 34T, 55 mm chain line, 170 mm length
Crank (Size: L, XL)
SRAM GX Eagle, DUB, T-Type, 34T, 55 mm chain line, 175 mm length
Bottom Bracket
SRAM DUB, 92 mm, PressFit
Cassette
SRAM Eagle XS-1275, T-Type, 10-52, 12-speed
Chain
SRAM GX Eagle, T-Type, 12-speed
Max. Chainring Size
1x: 38T, min 30T
Saddle
Verse Short Elite, hollow magnesium rails, 145 mm width
Seatpost (Size: S)
Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
Seatpost (Size: M, ML, L)
Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length
Seatpost (Size: XL)
Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Handlebar (Size: S)
Bontrager Kovee Pro, OCLV Carbon, 35 mm, 5 mm rise, 720 mm width
Handlebar (Size: M, ML, L, XL)
Bontrager Line Pro, OCLV Carbon, 35 mm, 15 mm rise, 750 mm width
Stem (Size: S, M)
Bontrager Elite, 35 mm, 13-degree, 60 mm length
Stem (Size: ML)
Bontrager Elite, 35 mm, 13-degree, 70 mm length
Stem (Size: L)
Bontrager Elite, 35 mm, 13-degree, 80 mm length
Stem (Size: XL)
Bontrager Elite, 35 mm, 13-degree, 90 mm length
Head Set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake
SRAM Level Bronze 4-piston hydraulic disc
Brake Rotor (Size: S, M, ML, L, XL)
SRAM CenterLine, 6-bolt, round-edge, 160 mm
Brake Rotor (Size: S, M, ML, L, XL)
SRAM CentreLine, 6-bolt, round-edge, 180 mm
Rotor Size
Max brake rotor sizes - Frame: 160mm, Fork: see fork manufacturer
Weight
M - 11.88 kg / 26.2 lbs (with TLR sealant, no tubes)
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
