Frame
OCLV Mountain Carbon, internal storage, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, guided internal routing, magnesium rocker link, 34.9 mm seat tube, ISCG 05, 55 mm chain line, BSA 73, downtube guard, shuttle guard, ABP, UDH, Boost148, 140 mm travel
Fork
Fox Factory 36, Float EVOL air spring, GRIP2 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 150 mm travel
Shock
Fox Factory Float X, 2-position damper, 185 mm x 55 mm
Wheel front
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless-Ready, 6-bolt, Boost110, 15 mm thru axle
Wheel rear
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost 148, 12 mm thru axle
Skewer rear
Bontrager Switch thru-axle, removable lever
Rim
Bontrager Line Pro 30, OCLV Mountain Carbon, Tubeless Ready
Tyre
Size: XS , S
Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 27.5x2.50"
Size: S , M , ML , L , XL
Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50"
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Rim strip
Bontrager TLR
Shifter
SRAM Eagle AXS, wireless, 12 speed
Rear derailleur
SRAM XX1 Eagle AXS
Crank
SRAM XX1 Eagle, DUB, 30T alloy ring, 55 mm chainline, 170 mm length
Bottom bracket
SRAM DUB MTB Wide, 73 m, BSA threaded
Cassette
SRAM Eagle XG-1299, 10-52, 12-speed
Chain
SRAM XX1 Eagle, 12-speed
Saddle
Bontrager Arvada, austenite rails, 138 mm width
Seatpost
Size: XS , S
RockShox Reverb AXS, 100 mm travel, wireless, 34.9mm, 340 mm length
Size: M , ML
RockShox Reverb AXS, 150mm travel, wireless, 34.9mm, 440mm length
Size: L , XL
RockShox Reverb AXS, 170mm travel, wireless, 34.9mm, 480mm length
Integrated Bar Stem
Size: XS , S
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 35mm stem length
Size: M , ML , L , XL
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 45mm stem length
Grips
Bontrager XR Trail Elite, nylon lock-on
Head set
Integrated cartridge bearing, 1-1/8" top, 1.5" bottom, angle adjust cup compatible
Brake rotor
Size: XS , S , M , ML , L , XL
SRAM HS2, 6-bolt, 180 mm
Size: M , ML , L , XL
SRAM 6-bolt, 200 mm
Brake Set
SRAM Code RSC hydraulic disc
