Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
Fork
Size: S Fox AWL Rail, Rail 2.0 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 180 mm direct mount, 100 mm travel, 27.5"
Fork
Size: M, L, XL Fox AWL Rail, Rail 2.0 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 180 mm direct mount, 120 mm travel, 29"
Max Compatible Fork Travel
See service manual
Wheel Front
Size: S Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 27.5"
Wheel Front
Size: M, L, XL Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"
Wheel Rear
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12 mm thru axle, 27.5"
Skewer Rear
Bontrager Switch thru axle, removable lever
Tyre
Size: S Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.60"
Tyre
Size: M, L, XL Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.60"
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
See service manual
Battery
Bosch PowerTube 800 Wh, smart system
Charger
Bosch standard 4A, 230V, smart system
Computer
Size: S, M, L, XL Bosch Kiox 300, smart system
Computer
Size: S, M, L, XL Bosch LED remote, smart system
Motor
Bosch Performance Line CX, 20 mph (25 km/h in Europe)
Shifter
Shimano SLX M7100, 12-speed
Rear Derailleur
Shimano XT M8100, long cage
Cassette
Shimano SLX M7100, 10-51T, 12-speed
Chain
Shimano SLX M7100, 12-speed
Pedal
VP-536 nylon platform
Max. Chainring Size
1x: 42T
Saddle
Bontrager Commuter Comp
Seatpost
Size: S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
Seatpost
Size: M, L, XL Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Handlebar
Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips
Bontrager XR Endurance Elite
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Head Set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake
Shimano 4-piston hydraulic disc, M6100 lever, M6120 calliper
Brake Rotor
Shimano RT66, 6-bolt, 203 mm
Rotor Size
Max brake rotor sizes – Frame: 203mm, min 180 mm, fork: see fork manufacturer
Tool
Bontrager Switch Lever, w/tool
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
