Frame
Alpha Platinum, Removable Integrated Battery (RIB 2.0), tapered headtube, internal routing, Motor Armour, rack and mudguard mounts, ABP, Boost 148, 120 mm travel
Fork
Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 130mm travel
Shock
Fox Float Rhythm, 2-position damper, 210x50 mm
Max Compatible Fork Travel
See service manual
Wheel Front (Size: S)
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 27.5"
Wheel Front (Size: M, L, XL)
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"
Wheel Rear (Size: S)
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, 27.5''
Wheel Rear (Size: M, L, XL)
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, 29''
Skewer Rear
Bontrager Switch thru-axle, removable lever
Tyre (Size: S)
Bontrager Gunnison Pro XR, Tubeless-Ready, wire bead, 60 tpi, 27.5x2.40"
Tyre (Size: M, L, XL)
Bontrager Gunnison Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29x2.40"
Tyre Part
Bontrager TLR sealant, 180 ml/6 oz
Rim Strip
Bontrager TLR
Max Tyre Size
Frame: 29x2.50" (S: 27.5x2.50"), Fork: see manufacturer
Battery
Bosch PowerTube 800 Wh, smart system
Charger
Bosch standard 4A, 230V, smart system
Computer (Size: S, M, L, XL)
Bosch Kiox 300, smart system
Computer (Size: S, M, L, XL)
Bosch LED remote, smart system
Motor
Bosch Performance Line CX, 20 mph (25 km/h in Europe)
Shifter
SRAM AXS POD
Rear Derailleur
SRAM GX Eagle AXS, T-Type
Crank
SRAM GX, 160 mm length
Cassette
SRAM Eagle XS-1275, T-Type,10-52, 12-speed
Chain
SRAM GX Eagle, T-Type, 12-speed
Pedal
VP-536 nylon platform
Max. Chainring Size
1x: 38T
Saddle
Bontrager Verse P3, steel rails
Seatpost (Size: S)
Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length
Seatpost (Size: M, L, XL)
Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length
Handlebar
Bontrager Comp, alloy, 31.8 mm, 40mm rise, 780 mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Stem
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
Head Set
FSA IS-2, 1-1/8" top, 1.5" bottom
Brake
SRAM DB 8 4-piston hydraulic disc
Rotor Size
Max brake rotor sizes – Frame: 220 mm, min 180 mm, Fork: see fork manufacturer
Weight Limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
